| Mounting |
Transom / Surface |
| Voltage |
Multivolt™ 12 / 24V DC Nominal |
| Max. Power Consumption |
Blue / White 70W / 5.9A @ 12V, 2.9A @ 24V
Edge Light <5W / 0.37A @12V, 0.2A @ 24V |
| Max. Light Output |
6000 lumen (White) |
| Colour Temperature |
5000K (White) |
| Beam |
90° x 24° |
| Protection |
Spike protected to +500 volts, Reverse polarity protected to -700 volts.
IP68 / IP69K: Suitable for submersion in operation and high pressure water jet cleaning.
High temperature thermal cutout for out of water. |
| Cable Length |
2.5m / 8.2ft, tinned marine cable |
Ideal Depth
Ideal Width |
100–500mm
600–1200mm |
| Lens Material |
Grilamid® (Premium grade, UV stable, impact resistant Nylon) |
| Base Material |
Marine grade bronze |
| Compliance |
EN55015 / CISPR 15, IEC60533, IEC61547, ICES-005, CE, RCM, UKCA |
